Characteristics of Press Forged Bearing Rings

Press forging is the production method of bearing ring forgings adopted by various bearing enterprises. The presses used are generally ordinary mechanical presses and inclined hole reamers. Bearing rings are forged on the press. In addition to some small forgings that are directly forged on the press, the press is generally connected with the hole reaming machine, and the assembly line is organized forged by one fire. The press provides the blank before the perforation, which reduces the requirements for forging of the press and expands the size of the forging that can be processed. Enclosure makes full use of the advantages of the tosing and expansion process, thus improving the production efficiency, the dimensional accuracy and internal quality of the forging. The advantages of press forging bearing rings are:

1. High quality of forgings. The metal is extruded into shape in the mold, the internal structure is uniform and dense, the surface of the forging is smooth, and the size accuracy is high. After being expanded, some of them directly roll out the raceway of the ring, and the metal streamline conforms to the working requirements of the bearing. Therefore, the life of the bearing is improved.

2. High production efficiency. There are few operators working on the assembly line, and the shift output is high.

3. Good process stability and strong process flexibility. Once the forging process of the press is successfully tested, it can be put into production steadily, and the process method can be flexible and changeable. It can be forged not only by large tonnage multi-station presses, but also by single-station multi-top small-tonnage presses.

4. The operation technology requirements are not high, and the working conditions are good.

5. The press is mechanically driven, and the working pressure is vertical static pressure, which is convenient for mechanization and automation of operation.

The author of this article is Shaanxi Gainhui Heavy Industries Co., Ltd., which is a professional bearing manufacturer and supplier in China. The company supplies many types of the bearings, such as needle bearing inner ring, ucp205 bearing, etc. With high quality and competitive bearing products, we sincerely provide services to customers all over the world.
