6021 ZZ Bearing

6021 ZZ Bearing

Material: Chrome steel(GCr15)
Precision: P0, P6, P5
Noise level and vibration: ZV, Z1V1, Z2V2, Z3V3, Z4V4
Radial clearance: C0, C3
Working temperature range: -30℃~120℃
Cage material: Steel
Tolerance standard: DIN 620-2
Free samples and technical drawing: Available
Certificate: ISO9001:2015
Feature: High-precision, Low-noise, Long-life

Description

Introduction:



If you're in the market for a high-quality, reliable bearing for your machinery or equipment, look no further than the 6021 ZZ Bearing! This top-of-the-line product is made with the highest-grade materials and precision manufacturing, ensuring exceptional performance and longevity.



Features:



The 6021 ZZ Bearing is specifically designed for heavy-duty applications, making it the perfect choice for machinery and equipment that sees lots of wear and tear. This product is made with high-quality chrome steel, which is known for its excellent durability and resistance to corrosion. The bearing is also designed with a double shield, which provides an extra layer of protection against contamination and debris.



One of the unique features of the 6021 ZZ Bearing is its high load capacity – thanks to its large, deep-groove ball design, this bearing is able to handle a higher load capacity than many other similar products on the market. This makes it an excellent choice for machinery that requires heavy lifting or continuous operation.



In addition to its strength and durability, the 6021 ZZ Bearing is also designed with precision in mind. The bearing's inner and outer rings are both machined to a high level of accuracy, ensuring smooth, consistent operation even under heavy loads. This also helps to reduce friction, which can help to extend the lifespan of your machinery and equipment.



Benefits:



There are many benefits to choosing the 6021 ZZ Bearing for your machinery and equipment needs. Here are just a few:



- High load capacity: The 6021 ZZ Bearing can handle heavy loads, making it an excellent choice for machinery and equipment that requires heavy lifting or continuous operation.



- Longevity: Thanks to its high-quality materials and precision manufacturing, this bearing is designed to last for years, even under heavy use.



- Reduced downtime: The 6021 ZZ Bearing is designed to operate smoothly and consistently, which can help to reduce downtime and increase productivity.



- Protection: The double shield design of this bearing provides an extra layer of protection against contamination and debris, which can help to extend the lifespan of your machinery and equipment.



Applications:



The 6021 ZZ Bearing is an excellent choice for a wide range of machinery and equipment applications. Here are just a few examples:



- Agricultural equipment: From tractors to combines, the 6021 ZZ Bearing is an excellent choice for heavy-duty agricultural equipment.



- Construction equipment: Whether you're working with excavators, loaders, or bulldozers, this bearing can handle the heavy loads and continuous operation required by construction equipment.



- Manufacturing equipment: From conveyor belts to industrial presses, the 6021 ZZ Bearing is an excellent choice for machinery used in manufacturing.



Conclusion:



Overall, the 6021 ZZ Bearing is an exceptional product that offers high load capacity, durability, and precision manufacturing. Whether you're in the agricultural, construction, or manufacturing industries, this bearing is an excellent choice for your machinery and equipment needs. So why wait? Contact us today to learn more about this top-of-the-line product and how it can benefit your business!



Introduction



6021 ZZ Bearing has good impact toughness and fracture toughness. When the it is subjected to a large local load during operation, a large contact stress will be generated between the ball and the ring, so the requirements for bearing steel are very high. The steel ball material used in our products is GCr15, which conforms to the GB/T 308.1-2013 standard. GCr15 is the most widely used bearing steel. It has high hardness, wear resistance and sufficient strength. It also has some toughness and corrosion resistance. Numerous advantages make it the perfect partner for bearings. Bearings are widely used in home appliances, instrumentation, roller skates, industrial pumps, gearboxes, tractors and other fields.


Sealing



Sealing is to prevent dust, water and other debris from entering the 6021 ZZ Bearing and prevent lubricant loss. There are two types of seals: external seals and integrated seals. Among them, the external seal can be divided into non-contact type and contact type according to factors such as the use environment. The non-contact outer seal does not directly contact the shaft, so there is no friction and wear, and it is suitable for high-speed rotation. The sealing performance of the contact external seal is better than that of the non-contact seal, but the friction force is large and the temperature rise is relatively high. The contact area between the shaft and the sealing ring needs to be lubricated, usually with the same lubricant as the bearing. In addition to using various oil seals, Z-type/V-type seals can also be used for sealing.


ina roller


Technical Parameters





6021 zz

skf bearing 6021 zz

Shoulder diameter outer ring

D1

Caliber diameter outer ring

D2

≈ 145.3 mm

Shoulder diameter inner ring

d1

≈ 121.7 mm

Diameter of shaft shoulder

da

min. 113.8 mm

Bore diameter

d

105 mm

Outside diameter

D

160 mm

Width

B

26 mm

Chamfer dimension

r

min. 2 mm

Diameter of housing shoulder

Da

max. 151.2 mm

Fillet radius

ra

max. 2 mm

Basic dynamic load rating

Cr

71 000 N

Basic static load rating

Cor

64 000 N

Fatigue load limit

Cur

3 100 N

Limiting speed

nG

3 800 r/min

Reference speed

nB

5 300 r/min

Mass

m

≈ 1.70 kg


Tolerance and Radial Clearance



Tolerance:DIN 620-2

Radial Clearance:ISO 5753−1

Dimensions

P0

P5

P6

C3

C0

Bore diameter

d

105 mm

-20 ~ 0 um

-10 ~ 0 um

-15 ~ 0 um

36 ~ 66 um

15 ~ 41 um

Outside diameter

D

160 mm

-25 ~ 0 um

-13 ~ 0 um

-18~ 0 um

Width

B

26 mm

-200 ~ 0 um

-200 ~ 0 um

-200 ~ 0 um


Noise Level and Vibration Level



Noise level:JB/T 7047

Vibration level:JB/T 10187

Dimensions

Z

Z1

Z2

Z3


V

V1

V2

V3

V4

Bore diameter

d

105 mm

60 dB

59 dB

58 dB

53 dB

L

560 um/s

340 um/s

250 um/s

170 um/s

88 um/s

Outside diameter

D

160 mm

M

490 um/s

300 um/s

215 um/s

145 um/s

88 um/s

Width

B

26 mm

H

670 um/s

420 um/s

310 um/s

200 um/s

135 um/s


FAQ (Frequently Asked Questions)



Q1: When can we get products?

A1: The general delivery time is 3-15 days. However, the actual situation still depends on the stock situation and the quantity.

Q2: Is your company a bearing manufacturer or operator?

A2: Our company integrates production and distribution. Committed to providing customers with excellent products.

Q3: How do you control the quality of the products?

A3: We have a professional quality inspection department. Products are inspected at the time of production or before they are shipped


Packing Methods



ntn 6304ntn 6903ntn 6207
Tube PackageSingle Box PackagePallet Package


Delivery Methods



ntn 6303ntn 6803ntn 6305
By ExpressBy SeaBy Air




Why choose us?

  • We are a Chinese factory that specializes in high-quality Deep Groove Ball Bearings products and services.
  • We will continue to forge ahead, accelerate development, and build our own global brand with 'character, responsibility, passion, and pioneering'.
  • Our company is committed to providing environmentally friendly and sustainable Deep Groove Ball Bearings products.
  • Innovation, enterprising, honesty and pragmatism are our entrepreneurial spirit.
  • Our Deep Groove Ball Bearings are versatile and can be used in a variety of applications and industries.
  • We take the science and technology as the forerunner, devotes to the automation, the informationization, the intellectualization, innovates unceasingly, provides the high quality 6021 ZZ Bearing for the customer.
  • We provide transparent and honest communication with our customers, so that they always know what to expect from our Deep Groove Ball Bearings products and services.
  • Our company attracts and recruits a large number of professionals, constantly improves the quality of products and services, and vigorously develops new 6021 ZZ Bearing to achieve large-scale operations.
  • Our Deep Groove Ball Bearings products are rigorously tested for durability, resistance to wear, and other important factors.
  • Give us a opportunity to show you our professionalism and enthusiasm.
